ACT 4060A

داراری جریان خروجی 2 آمپر
ولتاژ ورودی بین 4.5 تا 24 ولت
دارای محافظ گرمایی
نوع نصب :smd
package:SOP-8
نوع عملکرد ( Function Type) :مبدل 2 آمپر
FEATURES
• 2A Output Current
• Up to 96% Efficiency
• 4.5V to 24V Input Range
• 10µA Shutdown Supply Current
• 400kHz Switching Frequency
• Adjustable Output Voltage
• Cycle-by-Cycle Current limit Protection
• Thermal Shutdown Protection
• Frequency FoldBack at Short Circuit
• Stability with Wide Range of Capacitors,
Including Low ESR Ceramic Capacitors
• SOP-8 Package
APPLICATIONS
• TFT LCD Monitors
• Portable DVDs
• Car-Powered or Battery-Powered Equipments
• Set-Top Boxes
• Telecom Power Supplies
• DSL and Cable Modems and Routers
• Termination Supplies
GENERAL DE script ION
The ACT4060A is a current-mode step-down
DC/DC converter that provides up to 2A of output
current at 400kHz switching frequency. The device
utilizes Active-Semi’s proprietary high voltage
process for operation with input voltages up to 24V.
The ACT4060A provides fast transient response
and eases loop stabilization while providing
excellent line and load regulation. This device
features a very low ON-resistance power MOSFET
which provides peak operating efficiency up to 96%.
In shutdown mode, the ACT4060A consumes only
10μA of supply current.
This device also integrates protection features
including cycle-by-cycle current limit, thermal
shutdown and frequency fold-back at short circuit.
The ACT4060A is available in a SOP-8 package
and requires very few external devices for
operation.
